PRD12U-400D
PRD12U-400D
PRD12U-400D is OBSOLETE
Latest Model:
Replacement Product:
D4Q1-750-1
Description:
PRD12U-400D
Brochure (PRD12U)
Operating Manual (PRD12U)
$
3,155.00
Qty:
Add to Cart
In your cart
Add to Cart
Notify me when in stock
Description
Customer Reviews
Description
Model
PRD12U-400D
Part No
PRD12U-400D
Series
PRD12U
Horsepower
40.000
Rating kW
30.00
Input Voltage
200 - 240 +/- 10% (3P)
Input Phase
Three
Input Current
119.0
Output Voltage
Arm: 240VDC, Fld: 150VDC
Output Current
138.0000
Package Weight
43.0
Product Height
20.0000
Product Width
19.0000
Product Depth
11.0000
Summary
PRD12U-400D
Description
PRD12U-400D
Category
Drives
SubCategory
DC Drives
SubSubCategory
"Non-Regen.(A), 3 Phase"
Enclosure
OPEN
Control Method
"Full Wave, Six SCR"
Input Frequency Range
50 - 60 Hz
Options
Reversing
Manufacturer
Polyspede
Instantaneous Overcurrent Trip
Preset for 260% of rated current
Acceleration Deceleration
0.6 ~ 28 sec.
Minimum Speed
0 ~ 10% of output voltage
Maximum Speed
75 ~ 105% of output voltage
IR Compensation
0 ~ 10% boost
Armature Feedback
0.01
Tachometer Feedback
0.001
Speed Command Input
4 ~ 20 mA or 0 ~ 6 VDC
Tachometer Feedback Input
50VDC per 1000 RPM standard
