• Model
  • D4Q1-400
  • Part No
  • D4Q1-400
  • Series
  • D4Q1
  • Horsepower
  • 40.000
  • Rating kW
  • 30.00
  • Input Voltage
  • 380 - 480 +/- 10%
  • Input Phase
  • Three
  • Input Current
  • 60.0
  • Output Voltage
  • Arm: 500VDC, Fld: 300VDC
  • Output Current
  • 72.0000
  • Package Height
  • 17
  • Package Width
  • 17
  • Package Depth
  • 13
  • Package Weight
  • 26.0
  • Product Height
  • 11.7000
  • Product Width
  • 8.5000
  • Product Depth
  • 6.9000
  • Summary
  • D4Q1-400: Regenerative 40 HP, Digital 460V DC Drive
  • Description
  • 40 HP, 460 VAC, 72 Amps, D4Q1-400, Digital Regenerative, Variable Speed DC Drive
  • Category
  • Drives
  • SubCategory
  • DC Drives
  • SubSubCategory
  • "Regen.(D), 3 Phase"
  • Enclosure
  • NEMA 1 (IP20)
  • Control Method
  • "Digital (DC), Regenerative"
  • Input Frequency Range
  • 50 - 60 Hz
  • Other Functions
  • 17 Digital Inputs 8 Analog Inputs
  • Manufacturer
  • Polyspede
  • Armature Feedback
  • 0.02
  • Tachometer Feedback
  • 0.001
