D4Q1-3500
D4Q1-3500
Description:
350 HP, 460 VAC, 650 Amps, D4Q1-3500, Digital Regenerative, Variable Speed DC Drive
Brochure (D4Q1)
Operating Manual (D4Q1)
$
9,273.00
Qty:
Add to Cart
In your cart
Add to Cart
Notify me when in stock
Description
Customer Reviews
Description
Model
D4Q1-3500
Part No
D4Q1-3500
Series
D4Q1
Horsepower
350.000
Rating kW
275.00
Input Voltage
380 - 480 +/- 10%
Input Phase
Three
Input Current
478.0
Output Voltage
Arm: 500VDC, Fld: 300VDC
Output Current
650.0000
Package Height
36
Package Width
16
Package Depth
24
Package Weight
150.0
Product Height
27.6000
Product Width
10.0000
Product Depth
13.8000
Summary
D4Q1-3500: Regenerative 350 HP, Digital 460V DC Drive
Description
350 HP, 460 VAC, 650 Amps, D4Q1-3500, Digital Regenerative, Variable Speed DC Drive
Category
Drives
SubCategory
DC Drives
SubSubCategory
"Regen.(D), 3 Phase"
Enclosure
NEMA 1 (IP20)
Control Method
"Digital (DC), Regenerative"
Input Frequency Range
50 - 60 Hz
Other Functions
17 Digital Inputs 8 Analog Inputs
Manufacturer
Polyspede
Armature Feedback
0.02
Tachometer Feedback
0.001
